SmartLF Flex SGi Series
Get professional camera technology in an all new CCD scanner.
Available in 36” or 44” width, the Colortrac Flex SGi Series is the perfect solution for full color maps, architectural renderings, photographs, and any application requiring accurate, high definition color reproduction. Add an existing large format printer from any leading manufacturer, and you’ve got a state-of-the-art large format color copier.
Choose the highest quality scans for all your document types, and get it right the first time. Produce superior quality images and copies of 44/36 inch document width. Scan all types of paper and mounted documents with super easy and fast adjustment for different media thicknesses.
The standard SmartLF SGi Series scanners provide a face down, front loading, rear exit media path, but can also accommodate compact work areas with the optional Document Return Guide. By redirecting the scanned document back over the top of the scanner, the Flex SGi can be placed against a wall for maximum space utilization.
Basic Systems Specifications:
- Choose from SGi 36c, SGi 44c Colortrac scanners
- SFP (single foot print) system rack
- Rocket II Controller, 4GB of RAM, 500 GB hard drive, USB3. Integrated 10/100/1000 Gigabit Ethernet, Full Size Keyboard & Mouse. Windows 10 64-bit
- Integrated 19″ Widescreen Flat Panel Display
- SmartWorks Imaging Scan & Copy software
- 2-year on-site warranty
Suitable for:
- Hi-Fidelity colour reproduction for scanning and reprographics service professionals
- High Speed Technical Imaging within AEC, CAD, Mapping and GIS
- Electronic Document Capture (TWAIN)
Colortrac CCD Key Technologies
- LED illumination: long life, low energy and instant-on
- High speed Ethernet and USB3 interface: maintain high speed at high dpi – get more done
- Fast 8 ips color scan speed: high productivity
- Manual thick media system: fast, mechanically simple, low maintenance – quick and easy to use
- ScanOnce: Efficient scanning and copying workflow
- FireFly: SuperSpeed USB3
- SureDrive: Single driven media pressure roller
- ClearView: Innovative Dual LED lighting
- WinSync: Optimised Windows driver technology
| SGi 36c Flex Base/Pro | SGi 44c Flex Base/Pro | |
|---|---|---|
| Optical Resolution | 1200 dpi | 1200 dpi |
| Extended Resolution | 9600 dpi | 9600 dpi |
| Max Scan Width | 36in (91.4 cm) | 44in (111.8cm) |
| Max Media Width / Thickness | 46in (116.9 cm) / 0.6” (15.0 mm) | 46in (116.9 cm) / 0.6” (15.0 mm) |
| Scan Accuracy | +/-0.1% +/-1 pixel | +/-0.1% +/-1 pixel |
| Imaging Technology | 6 x CCDs each with red, green, blue and gray sensor lines. 48-bit color image capture, 16-bit grayscale image capture, black & white (panchromatic full spectrum) |
|
| Data Capture (color/grayscale) | 48-bit / 16-bit | 48-bit / 16-bit |
| Color Space | Adobe RGB, Profiled RGB, sRGB and RAW RGB | |
| Scan Speed – 8-bit grayscale/mono (inch/sec) @200dpi |
13 ips | 13 ips |
| Scan Speed – 24-bit color (inch/sec) @200dpi |
4 ips | 4 ips |
| Paper Path | Face-down, Front entry, Rear exit, Side load | |
| Interface | USB 3.0 data transfer rates up to 85MB/sec. Gigabit Ethernet. 2m long USB3 and Gigabit Ethernet cables supplied | |
| Power Requirements | External power supply 100~240VAC auto-sensing +/-10%, 50-60Hz Scanner power consumption: | |
| Included Software | SmartWorks Imaging Scan & Copy | SmartWorks Imaging Scan & Copy |
| Rocket Controller (Available on the Flex Pro only) |
Rocket Controller – 3.1Ghz core processor (64-bit Processing), 4GB of RAM (upgradable), 500 GB hard drive. Integrated 10/100/1000 Gigabit Ethernet, Full Size Keyboard & Mouse. Windows 10 Professional 64-bit – optional touchscreen available |
|
| Warranty | 2-Year Onsite | 2-Year Onsite |
| SGi Flex Base Includes: SmartLF SGi 36 or SGi 44 scanner, external scanner power supply, USB 3 cable, document return guides, adjustable Repro Stand with keyboard tray and monitor mounting bracket, SmartWorks Imaging Scan & Copy , Rocket scanner controller (Pro model only). The Repro Stand height is adjustable through four height variations allowing maximum printer heights between 39in (988 mm) and 45in (1143 mm). | ||
