Colortrac SmartLF SCi 36 Scanner
THREE versions available:
- SCi 36m Monochrome captures wide dynamic range of b&w photos & CAD drawings at speeds up to 13 ips
- SCi 36c Color adds wide color gamut scanning to the 42m with color scan speeds up to 6 ips
- SCi 36e Enhanced Color adds enhanced wide color gamut scanning at speeds up to 12 ips
KEY FEATURES:
- 200% improvement of scan speeds at 200 dpi and 300 dpi
- Control SmartWorks IMAGING right on the scanner (Tablet Optional)
- Single Sensor: Unique Colortrac CIS modules
- FireFly: SuperSpeed USB3
- ClearView Innovative Dual LED lighting
- WinSync Optimised Windows driver technology
- ScanOnce Efficient scanning and copying workflow
- SureDrive Single driven media pressure roller
The SmartLF I Series – great scanners made even better
The Colortrac SmartLF SCi series scanners are perfect for everyday scanning tasks. An A0 / E size document can be scanned in full color at 12 inches per second, only 1 inch per second slower than its black and white scan speed. Connection to the host computer is straightforward and uses a standard USB 3.0 cable which is supplied with the scanner.
SingleSensor Technology
Colortrac SmartLF SCi series scanners feature one-piece scanning sensors spanning the full scan width of the device. Only from Colortrac, the appropriately named SingleSensor combines sensors and illumination in a single scan line for unbeatable ‘all-over’ scan accuracy and best-possible document illumination. Simple and reliable, SCi series scanners deliver high-quality scanning at an affordable cost.
NEW SmartWorks Imaging
Optimized all the way through, SmartWorks Imaging is clearer and easier to navigate than SmartWorks Pro. With a faster performance, revised preset control, better printer drivers and a new multi-page thumbnail pop-out feature, SmartWorks Imaging is the perfect productivity partner for SmartLF SCi and SmartLF SGi large format scanners.
LINK Remote Control
Work smarter with LINK. This portable tablet app works with any computer already connected to the scanner and running SmartWorks Imaging to bring effortless control of the scanner to your fingertips. Use LINK to reduce body movement and to improve operator comfort while scanning.
Large Document Staging Area
SmartLF SCi scanners have a large, easy-to use staging platform that accepts documents for scanning face-upwards. Specifically designed to auto-detect the size of documents placed in the center of the scanner, documents can be loaded and prepared for scanning in just a few seconds. Documents conforming to standard drawing sheet sizes (manual mode) can be placed in the center or to the side depending on the choice of software. Magnetic paper guides are also provided ot make positioning easier. SCi 36 scanners have a maximum media width of 38” (965mm) and are able to scan documents and maps up to a thickness of 0.08″ (2 mm).
Dynamic Document Feed
Unlike scanners using staggered sensors SmartLF SCi benefits from a simplified pressure roller arrangement to ensure that the document always stays in contact with the optics. The rollers either side of the scan line and the active soft pressure roller running the length of the SingleSensor are all motor driven allowing the scanner to dynamically respond and actively work against optical disturbances caused by creases and uneven documents. This unique technology ensures that delicate or fragile media such as newspaper and old blueprints can be safely and accurately scanned without problem.
SuperSpeed PC Interface
SmartLF SCi 36 uses a SuperSpeed USB 3.0 digital interface that allows the scanner to work at full speed on full width documents or to scan smaller documents at higher resolutions more quickly. Improved productivity is easy to achieve with the time-saving innovations built into every Colortrac I series scanner.
INCLUDED SOFTWARE:
Colortrac SmartLF SCi 36 scanners include the NEW! SmartWorks TOUCH Scan/Copy/Email software that combines wide format scanning and copying in one very easy to use program and has full compatibility with wide format printers through standard Windows drivers. SmartWorks TOUCH is optimized for use with touch-screen monitors using a simple, intuitive user interface suitable for general office use.
Floor Stand
Minimizes the installed footprint of your wide format scanner and positions the document feed at a comfortable and convenient height. A basket catches scanned documents as they are ejected from the scanner and collects them at the back of the scanner for recovery later.
Document Return Guide
The SmartLF SCi scanners have an optional Document Return Guide that allows users to have scanned documents directed over the top of the scanner to the front for easy retrieval. It also allows users to place the scanner on desktops or on Floor Stands against walls to minimize the overall footprint and to maintain the operators ease of use when space around the scanner is restricted.
PC and Flat Screen Mounting Option
PC and LCD flat screen mounting option combines wide format scanner and computer into a self-contained scan processing station that can be moved around an office as required. The PC and flat screen mounting kit requires the floor stand.
PC, flat screen, keyboard & mouse are optional
Repro Stand
An alternative floor stand that holds the scanner above most popular large format printers including products from HP, Canon, Epson and other printer manufacturers. Repro Stand conveniently holds a PC, flat screen and mini-keyboard and minimizes the combined footprint of scanner and printer creating a practical, high productivity workstation. Scanner height is adjustable through four height settings.
Maximum height of the printer that can be accommodated under the Repro Stand is 45.5″ (115.5 cm). There is no limit to the width of the printer.
PC, flat screen, keyboard & mouse are optional
Document Carrier Sheets
Available in ARCH D/A1 and ARCH E/A0 size, with black or white backing sheet. Hinged on the short side.
- Scan and protect dry, ageing and/or valuable documents.
- Protect the scanner glass from documents contaminated with storage dirt and dust.
- Scan badly torn documents or documents with missing edges.
- Scan multiple lightweight and/or odd shaped originals & upholstery patterns.
- Scan transparencies more effectively.
- White backing sheet improves light reflection and scan quality.
- Black backing sheet prevents the back side image appearing underneath the image of the front side when scanning newspapers, double-sided maps and other semi-transparent originals printed on both sides.
